Frontier LP7500 - No. 06138 Paper Advance Arm Motor (Left) Operation Error

4. Troubleshooting
46100
11/33
46100
Error message: Printer 2
No. 06138
Paper Advance Arm Motor (Left) operation error.
No. 06139
Paper Advance Arm Motor (Right) operation error.
Error message release
NO
Condition
Check Point
Diagnosis
$ Symptoms due to connection failure of wiring/symptoms resulted from blowout of fuse
NOTE
• To access the wiring diagrams, click Wiring diagrams in Bookmarks.
Suffix number Condition
00001 The arm sensor (left) or (right) does not turn DARK even though the paper advance arm motor (left) or (right)
has operated for a specified pulse.
00002 The arm sensor (left) or (right) does not turn LIGHT even though the paper advance arm motor (left) or (right)
has operated for a specified pulse.
1 Clean the arm sensor (right or left). ☞63100
Operation failure Manual No.
Paper advance arm motor (right or left)
☞63100
Printer I/O PCB 3 ☞66040
Printer I/O PCB 1 ☞66020
Printer control PCB ☞66000
Detection failure Manual No.
Arm sensor (right or left) ☞63100
Printer I/O PCB 3 ☞66040
Printer control PCB
☞66000
Symptoms due to the wiring connection failure Symptoms of fuse blowout
☞4202 − ☞4252
