Frontier LP7500 - No. 06012 Paper DID Not Load. Paper Magazine a; No. 06013 Paper DID Not Load. Paper Magazine B

Error message: Printer 1
1/15
4. Troubleshooting
46000
46000
Error message: Printer 1
No. 06012
Paper did not load. Paper Magazine A
No. 06013
Paper did not load. Paper Magazine B
Error message release
YES
Condition
NOTE
• For details about magazine initial operation, see 55100 ☞Performs magazine initial operation.
Check Point
Diagnosis
$ Symptoms due to connection failure of wiring/symptoms resulted from blowout of fuse
Error message No. Condition
No. 06012 Paper cannot be loaded from paper magazine A.
No. 06013 Paper cannot be loaded from paper magazine B.
Suffix number Condition
00001 Even though a specified length of paper is advanced after the paper loading has started, paper end sensor A and
B do not turn DARK during setup or printing of the mechanical adjustment.
00002 Even when a specified length of paper is advanced after the paper end sensors A and B have turned dark, the
loading sensor does not turn DARK.
00003 When magazine initial operation is performed, paper is rewound until the paper end sensor stops detection and it
is advanced to the paper loading sensor position. However, the loading sensor does not detect DARK.
1 Check that the paper is correctly inserted into the paper magazine.
2 Clean the advance roller.
Advance failure Manual No.
Paper magazine motor A or B ☞63051
Paper supply motor A, B or C ☞63060
Printer I/O PCB 2
☞66030
Printer I/O PCB 1
☞66020
Printer control PCB
☞66000
Printer power supply 2
☞66100
Triple magazine PCB ☞66050
Detection failure (paper end sensor) Manual No.
Paper end sensor A or B
☞63051
Printer I/O PCB 3 ☞66040
Printer control PCB ☞66000
Detection failure (paper loading sensor) Manual No.
Paper loading sensor ☞66030
Printer I/O PCB 2 ☞66030
Printer control PCB
☞66000
Symptoms due to the wiring connection failure Symptoms of fuse blowout
☞4202 − ☞4252
