4. Troubleshooting
45500
9/14
45500
Error message: Processor 1
No. 05511
The circulation pump has stopped. CD
No. 05512
The circulation pump has stopped. CD2
No. 05513
The circulation pump has stopped. BF
No. 05514
The circulation pump has stopped. BF2
No. 05515
The circulation pump has stopped. STB1
No. 05516
The circulation pump has stopped. STB2
No. 05517
The circulation pump has stopped. STB3
No. 05518
The circulation pump has stopped. STB4
Alarm release
NO
Error message release
YES
Condition
Check Point
Diagnosis
$ Symptoms due to connection failure of wiring/symptoms resulted from blowout of fuse
Error message No. Condition
No. 05511-00000 The rotation detector built in the P1 circulation pump detects that the pump has stopped rotating.
No. 05512-00000 The rotation detector built in the P1-2 circulation pump detects that the pump has stopped rotating.
No. 05513-00000 The rotation detector built in the P2 circulation pump detects that the pump has stopped rotating.
No. 05514-00000 The rotation detector built in the P2-2 circulation pump detects that the pump has stopped rotating.
No. 05515-00000 The rotation detector built in the PS1 circulation pump detects that the pump has stopped rotating.
No. 05516-00000 The rotation detector built in the PS2 circulation pump detects that the pump has stopped rotating.
No. 05517-00000 The rotation detector built in the PS3 circulation pump detects that the pump has stopped rotating.
No. 05518-00000 The rotation detector built in the PS4 circulation pump detects that the pump has stopped rotating.
1 Check that the filter cartridge is not soiled.
Failed part Manual No.
Circulation pump ☞63290
Processor I/O PCB 1 ☞66210
Processor relay PCB
☞66220
Processor control PCB ☞66200
Symptoms due to the wiring connection failure Symptoms of fuse blowout
−
☞4203 ☞4252
