8/14
4. Troubleshooting
45500
45500
Error message: Processor 1
No. 05510
Processor A/D conversion error.
Alarm release
NO
Error message release
NO
Condition
IMPORTANT
• The A/D conversion is a process to convert analog data of the temperature measured by the processing solution
thermosensor, the dryer thermosensor and the inner thermosensor into digital data via the processor control PCB.
Diagnosis
$ Symptoms due to connection failure of wiring/symptoms resulted from blowout of fuse
NOTE
• To access the wiring diagrams, click Wiring diagrams in Bookmarks.
Suffix number Condition
00000 The analog data detected by each thermosensor cannot be converted to digital data.
Failed part Manual No.
Thermosensor
☞63290
Dryer thermosensor ☞63260
Processor power supply 2 ☞67400
Processor control PCB
☞66200
Symptoms due to the wiring connection failure Symptoms of fuse blowout
− ☞4203 −
