4. Troubleshooting
40700
6/6
40700
Attention message: SM replenishment
No. 00705[SM]
Replace the Replenishment Package with a new one.P-#
Attention message release
YES
This attention message will be closed only when the replenishment package is removed. (You have to turn off the replenishment package
sensor once.)
Condition
NOTE
• If the tank is refilled forcibly after SM replenishment has been set via Machine Specification, these messages appear.
• A suffix number is indicated by the decimal number.
Check Point
Diagnosis
NOTE
• To access the wiring diagrams, click Wiring diagrams in Bookmarks.
Suffix number Condition
00001 While replenishment solution sensor CD-A turns DARK, the remaining replenishment tanks are refilled forcibly.
00002 While replenishment solution sensor CD-B turns DARK, the remaining replenishment tanks are refilled forcibly.
00004 While replenishment solution sensor CD-C turns DARK, the remaining replenishment tanks are refilled forcibly.
00008 While replenishment solution sensor STB turns DARK, the remaining replenishment tanks are refilled forcibly.
00016 While replenishment solution sensor BF-A turns DARK, the remaining replenishment tanks are refilled forcibly.
00032 While replenishment solution sensor BF-B turns DARK, the remaining replenishment tanks are refilled forcibly.
1 Check that the replenishment solution sensor is not soiled.
Adjustment failure point Manual No.
Sensitivity of the replenishment solution sensor ☞63300
Failed part Manual No.
Replenishment solution sensor
☞63300
SM I/O PCB ☞66600
Processor control PCB ☞66200
