3/4
4. Troubleshooting
45700
45700
Error message: SM replenishment
No. 05710[SM]
Refilling water operation error. CD-W
No. 05711[SM]
Refilling water operation error. BF-W
No. 05712[SM]
Refilling water operation error. STB1-W
No. 05713[SM]
Refilling water operation error. STB2-W
No. 05714[SM]
Refilling water operation error. STB3-W
No. 05715[SM]
Refilling water operation error. STB4-W
Error message release
YES
Condition
Check Point
Diagnosis
Error message No. Condition
No. 05710-00000 The refilling water level detector of the CD processing solution float switch does not turn ON even
though a specified time has passed since refilling water operation started.
No. 05711-00000 The refilling water level detector of the BF processing solution float switch does not turn ON even
though a specified time has passed since refilling water operation started.
No. 05712-00000 The refilling water level detector of the STB1 processing solution float switch does not turn ON even
though a specified time has passed since refilling water operation started.
No. 05713-00000 The refilling water level detector of the STB2 processing solution float switch does not turn ON even
though a specified time has passed since refilling water operation started.
No. 05714-00000 The refilling water level detector of the STB3 processing solution float switch does not turn ON even
though a specified time has passed since refilling water operation started.
No. 05715-00000 The refilling water level detector of the STB4 processing solution float switch does not turn ON even
though a specified time has passed since refilling water operation started.
1 Check if the processing solution is leaking from the tank.
2 Check that the hoses from the water supply pump and refilling water pump are not clogged.
3 Check that the processing float switch moves smoothly.
When water is incorrectly added Manual No.
Water Supply Pump ☞63300
Refilling water pump
☞63300
SM I/O PCB ☞66600
Processor I/O PCB 1 ☞66210
Processor control PCB
☞66200
When refilling water is incorrectly detected Manual No.
Processing solution float switch ☞63300
Processor relay PCB ☞66200
Processor control PCB
☞66200
