10/14
4. Troubleshooting
45530
45530
Error: Processor 2
No. 05545
Print Sensor (Left) error.
No. 05547
Print Sensor (Right) error.
No. 05548
Dryer Lane Select Sensor error.
No. 05553
Print sensor (center) error
Error message release
YES
Condition
Check Point
NOTE
• In the service mode, LED light intensity value is displayed in the Print Sensor Adjustment Display.
• After cleaning each sensor, carry out Print Sensor LED Light Intensity Adjustment again and check that the sensor LED light
intensity changes.
Diagnosis
NOTE
• To access the wiring diagrams, click Wiring diagrams in Bookmarks.
Suffix number Condition
-When Print Sensor LED Light Intensity Adjustment was performed, the system could not adjust it normally.
Suffix number Condition
00001 When the standard voltage was set to 7.5 V and the light source level was set to 0, the print sensor did not change to
LIGHT.
00002 If the standard voltage was set to 7.5 V and the light source level was set to 255, the print sensor did not detect LIGHT.
In addition, although the standard voltage was set to 4.0 V, the print sensor did not detect light.
00003 Even if the standard voltage was changed from 7.5 V to 4.0 V for the light source level, the print sensor did not detect
LIGHT.
1 Clean each sensor using a blower brush.
2 Perform Print Sensor LED Light Intensity Adjustment of Functions via Print Sensor Adjustment.
See
☞33001.
Failed part Manual No.
Print sensor (Right) (Center) (Left)
☞63260
Dryer lane select sensor
Processor control PCB ☞66200
