Frontier LP7500 - Processor Section (List of Adjustment after Electrical Parts Replacement) [F

Positions of electrical parts (Processor section)
1/1
6. Electrical parts
63312
63312
Processor section (List of adjustment after electrical parts replacement) [F]
*1. P1R, P2RA, P2RB and P1R cartridge flushing valves are to be replaced as a set.
*2. P1, P2 and P3 cartridge flushing valves are to be replaced as a set.
*3. # # #(upper) replenishment solution level sensor and # # #(lower) replenishment solution level sensor are to be replaced as a set.
Item Adjustment option after replacement Reference
P1R Replenisher Pump Replacing • Perform Pump Output Amount Measurement. ☞33003
P2RA Replenisher Pump
P2RB Replenisher Pump
PSR Replenisher Pump
P1R cartridge flushing valve
*1
Replacing • Perform Measure Auto Cleaning Water Output
Amount of Auto Cleaning Water Output Amount
Setting.
☞33004
P2RA cartridge flushing valve
*1
P2RB cartridge flushing valve
*1
P1R agitation solenoid valve
*1
• If necessary, perform Output Check for the
cartridge flushing valve and replenishment
cartridge cleaning pump.
☞27540
P1 automated cleaning valve
*2
P2 automated cleaning valve
*2
PS automated cleaning valve
*2
Replenisher cartridge cleaning pump Replacing • Perform Initial Replenishment Operation of Auto
Cleaning Water Output Amount Setting.
• Perform Measure Auto Cleaning Water Output
Amount of Auto Cleaning Water Output Amount
Setting.
☞33004
P1R (Upper) Replenishment Solution Level
Sensor
*3
Replacing • Replacing the replenishment solution level sensor
• If necessary, perform Recovery procedure from the
replenishment error 1 or Recovery procedure
from the replenishment error 2.
☞27530
☞4610
☞4620
P1R (Lower) Replenishment Solution Level
Sensor
*3
P2RA (Upper) Replenishment Solution Level
Sensor
*3
P2RA (Lower) Replenishment Solution
Level Sensor
*3
P2RB (Upper) Replenishment Solution Level
Sensor
*3
P2RB (Lower) Replenishment Solution
Level Sensor
*3
Replenishment cartridge opening motor Replacing • If necessary, perform Replenishment cartridge
installation section troubleshooting flow.
☞4600
Replenisher Cartridge Position Sensor
(Upper)
Replenisher Cartridge Position Sensor
(Lower)
