6. Electrical parts
63311-5
63311-5
Positions of electrical parts (Processor section)
24 STB-W water supply pump RP3
25 CD-A replenisher pump RP5
26 CD-B replenisher pump RP6
27 CD-C replenisher pump RP7
28 BF-A replenisher pump RP8
29 BF-B replenisher pump RP9
30 STB replenisher pump RP10
No. Name Symbol Remarks
