Attention message: SM replenishment
1/6
4. Troubleshooting
40700
40700
Attention messag e: SM replenish ment
No. 00700[SM]
Replace the Replenishment Package with a new one.P-#
Attention message release
YES
This attention message will be closed only when the replenishment package is removed. (You have to turn off the replenishment package
sensor once.)
Condition
NOTE
• When the tank is not refilled forcibly whether or not to set SM Replenishment Setting via Machine Specification, these messages
appear. When the following conditions, the tanks are not refilled forcibly.
• A suffix number is indicated by the decimal number.
Check Point
Diagnosis
NOTE
• To access the wiring diagrams, click Wiring diagrams in Bookmarks.
Suffix number Condition
00001 While replenishment solution sensor CD-A turns DARK, the remaining replenishment tanks are not refilled
forcibly.
00002 While replenishment solution sensor CD-B turns DARK, the remaining replenishment tanks are not refilled
forcibly.
00004 While replenishment solution sensor CD-C turns DARK, the remaining replenishment tanks are not refilled
forcibly.
00008 While replenishment solution sensor STB turns DARK, the remaining replenishment tanks are not refilled
forcibly.
00016 While replenishment solution sensor BF-A turns DARK, the remaining replenishment tanks are not refilled
forcibly.
00032 While replenishment solution sensor BF-B turns DARK, the remaining replenishment tanks are not refilled
forcibly.
SM Replenishment Setting Detecting condition of the replenishment solution sensor
ON The replenishment solution is not detected when the power is on.
The replenishment solution is not detected when the replenishment package is replaced.
The replenishment solution is not detected during output checks.
The replenishment solution is not detected while measuring the output amount.
The replenishment solution is not detected while initial replenishing.
Each replenishment solution in the replenishment package is not detected at the same time.
OFF Forced replenishment is not carried out.
1 Check that the replenishment solution sensor is not soiled.
Adjustment failure point Manual No.
Sensitivity of the replenishment solution sensor ☞27830
Failed part Manual No.
Replenishment solution sensor
☞63300
SM I/O PCB ☞66600
Processor control PCB ☞66200
