4. Troubleshooting
46100
46100
Error message: Printer 2
No. 06137
Exposure Advance Pressure Change Motor 2 operation error.
Error message release
NO
Condition
Diagnosis
$ Symptoms due to connection failure of wiring/symptoms resulted from blowout of fuse
NOTE
• To access the wiring diagrams, click Wiring diagrams in Bookmarks.
Suffix number Condition
00001 Exposure advance pressure change sensor 2 does not turn DARK from LIGHT even though the exposure
advance pressure change motor 2 has moved for the specified length.
00002 Exposure advance pressure change sensor 2 does not turn LIGHT from DARK even though the exposure
advance pressure change motor 2 has moved for the specified length.
Operation failure Manual No.
Exposure advance pressure change motor 2
☞63070
Printer I/O PCB 1 ☞66020
Printer control PCB ☞66000
Detection failure Manual No.
Exposure advance pressure change sensor 2 ☞63070
Printer I/O PCB 3 ☞66040
Printer control PCB
☞66000
Symptoms due to the wiring connection failure Symptoms of fuse blowout
☞4202 − ☞4252
