3. Mode
35920
2/2
35920
Self-diagnostic
!
!!
! Checking procedure
1. Select a Test Item.
NOTE
• When selecting Test Print, select a test print image.
2. The dialog for the Image Path Check appears by clicking Start Test. Click YES to start the test.
3. Assumable failed parts are displayed on the Diagnostic Contents column.
NOTE
• ← indicates it is same as on the left.
• − stands for unused.
Save Result Allows you to save the result of Image Path Check in a file.
IMPORTANT
• The test result is saved in C:\NoritsuKoki\QSS-##\LogData\DiagLogImgPass.Log.
QSS-37
• C:\NoritsuKoki\Printer\QSS-Printer\ [Serial number folder of the output system] \Log
LP7500/LP7600/LP7700/LP7900
• D:\NoritsuKoki\Printer\FRONTIER-Printer\ [Serial number folder of the output system]
\Log
• Only one file is available to save the result.
Clear Result Deletes the result of Image Path Check.
Result Displays the result of the test after Image Path Check is completed.
Diagnostic Contents
Printer I/F main PCB
Laser control PCB
Item Explanation
