3. Mode
36070
36070
Printer Mechanical Adjustment
6. Measure dimension B from the left end to the center line on the test print.
IMPORTANT
• When measuring the test print, use the front end of the test print.
7. Carry out correction so that dimension B is half of the paper width.
8. After correcting, carry out Test Print Confirmation with Master and Paper Magazine Values of F:
Functions and be sure to make a print to check if the exposure center is correct.
B is longer than a half of the
paper width
Negative correction
A half of the paper width is
longer than B
Positive correction
Center line
Front end of the test print
G068464
