3. Mode
36100
2/2
36100
Printer Mechanical Adjustment
NOTE
• A magenta arrow is shown on the Test Print Confirmation print.
• A piece of paper with the advance length of 216 mm and the margin of 5.0 mm is printed.
• The paper width, 〈A ####(#)〉 is printed as the CVP imprinting.
!
!!
! White Border Width Correction
IMPORTANT
• If the margin on the test print is 0.5 mm, the correction is not necessary.
1. Check that the zigzagging adjustment of the magazine mount has been completed.
☞22100
2. Check that the exposure center correction has been completed.
☞36070
3. Carry out Test Print of F: Functions.
4. Measure the right and left margins on the test print.
5. Enter the measured value in each item.
6. Carry out Test Print Confirmation of F: Functions and make sure that the margin is 5.0 mm.
Test print
Test Print (Confirmation)
G066121
G068472
