4. Troubleshooting
4202
4202
Diagnosis appendix for the failures: Symptom due to the connection failure of wiring
!
!!
! Printer I/O PCB 2
J/P249 Connects to exposure
advance motors 1 and 2.
No.06208-00001 Paper has jammed in the Paper Supply Unit. occurs.
J/P250 Connects to paper magazine
motors B and C.
No.06112-00001 Could not load the paper. Paper Magazine C or No.06112-00001 Could
not load the paper. Paper Magazine C occurs when printing is started.
J/P251 Inputs the power supply
(IL24 V-2) from printer
power supply 1.
No.06136-00001 Exposure Advance Pressure Change Motor 1 operation error. occurs.
J/P252 Connects to printer I/O PCB
2.
No.06101-00001 Paper Hold Motor operation error. occurs.
J/P253 Connects to the triple
magazine unit PCB (option).
No.06012-00001 Paper did not load. Paper Magazine A occurs when printing is started.
Connects to the quad
magazine PCB (option).
No malfunctions in the operations will occur on this condition.
J/P254 Inputs the power supply
from printer power supply 2
(+36V)
No.06013-00001 Paper did not load. Paper Magazine B occurs when printing is started
using magazine B.
J/P255 Connects to the CVP PCB. The CVP unit does not operate.
J/P256 Connects to paper advance
motor 2.
No.06049-00001 Pressure Guide operation error. occurs.
J/P257 Connects to control box
cooling fan 1.
Control box cooling fan 1 does not rotate.
Connector No. Symptom
J/P258 Connects to the paper cut
motor.
No.06016-00004 Paper Cutter operation error. occurs when printing is started.
J/P259 Connects to the paper hold
motor and paper hold sensor.
No.06101-00002 Paper Hold Motor operation error. occurs.
J/P260 Connects to the paper supply
pressure change sensor and
paper supply pressure
change motor.
No.06134-00002 Paper Supply Pressure Change Motor operation error. occurs.
J/P261 Connects to the cut home
sensor and cut end sensor
No.06016-00004 Paper Cutter operation error. occurs.
J/P262 Connects to the printer
control PCB.
No.06016-00004 Paper Cutter operation error. occurs.
J/P263 Power supply (IL5V) from
the printer I/O PCB 1
No.06016-00004 Paper Cutter operation error. occurs.
J/P264 Power supply (IL36 V,
IL24V) from printer I/O
PCB 1
No.06012-00001 Paper did not load. Paper Magazine A occurs when printing is started.
J/P265 Connects to paper advance
motor 1.
No.06135-00001 Arm Unit 1 operation error. occurs when printing is started.
J/P266 Connects to the paper supply
motor B/C and paper supply
arm motor (right).
No.06135-00001 Arm Unit 1 operation error. occurs.
J/P267 Paper supply motor A (when
the triple magazine/quad
magazine is connected)
No.06012-00002 Paper did not load. Paper Magazine A occurs when printing is started.
J/P268 Paper supply motor (left) No.06135-00001 Arm Unit 1 operation error. occurs.
Connector No. Symptom
