4. Troubleshooting
45500
13/14
45500
Error message: Processor 1
No. 05524
Refilling water operation error. CD-W
No. 05525
Refilling water operation error. BF-W
No. 05526
Refilling water operation error. STB1-W
No. 05527
Refilling water operation error. STB2-W
No. 05528
Refilling water operation error. STB3-W
No. 05529
Refilling water operation error. STB4-W
Alarm release
NO
Error message release
YES
Condition
NOTE
• The CD, BF and STB4 processing solution float switches have a processing solution level detector, a refilling water level detector and
a safety thermostat for each.
The STB3, 5 and 6 processing solution float switches have a refilling water level detector for each.
Check Point
Diagnosis
Error message No. Condition
No. 05524-00000 The refilling water level detector of the CD processing solution float switch does not turn on even though a
specified time has passed since refilling water operation started.
No. 05525-00000 The refilling water level detector of the BF processing solution float switch does not turn on even though a
specified time has passed since refilling water operation started.
No. 05526-00000 The refilling water level detector of the STB1 processing solution float switch does not turn on even though a
specified time has passed since refilling water operation started.
No. 05527-00000 The refilling water level detector of the STB2 processing solution float switch does not turn on even though a
specified time has passed since refilling water operation started.
No. 05528-00000 The refilling water level detector of the STB3 processing solution float switch does not turn on even though a
specified time has passed since refilling water operation started.
No. 05529-00000 The refilling water level detector of the STB4 processing solution float switch does not turn on even though a
specified time has passed since refilling water operation started.
1 Check if the processing solution is leaking from the tank.
2 Check if the float of the processing solution float switch moves up and down smoothly.
3 Check that the hoses from the refilling water pumps CD-W, BF-W, STB1-W, STB2-W, STB3-W, and STB4-W
to the sub-tank are not clogged.
When water is incorrectly added Manual No.
Refilling water pump ☞ 63290
Processor I/O PCB 1
☞66210
Processor control PCB
☞66200
