4. Troubleshooting
45600
5/5
45600
Error message: Tablet replenishment
No. 05613[J]
The processing solution level is too low. STB1
Error message release
YES
Condition
Check Point
Diagnosis
NOTE
• To access the wiring diagrams, click Wiring diagrams in Bookmarks.
Suffix number Condition
00000 When the processing solution level detector of the STB1 processing solution float switch turns off and water
supply is carried out for a given amount of time, the processing solution level detector keeps off.
1 Check if the processing solution is leaking from the tank.
2 Check that the valve of the strainer unit is not closed.
3 Clean the strainer.
4 Check if the replenisher hose are not clogged.
5 Check the output amount.
6 Check if the float of the processing solution float switch moves up and down smoothly.
Failed part Manual No.
STB1 processing solution float switch ☞63310
STB water supply pump ☞63310
Processor relay PCB
☞66220
Processor control PCB ☞66200
Processor I/O PCB 1 ☞66210
