Error message: Colorimeter
1/3
4. Troubleshooting
46550
46550
Error m essage: Co lorime ter
No. 06551
Paper has jammed in the Colorimeter Unit.
Error message release
YES
Condition
NOTE
• Refer to the setup print color measuring operation flow. ☞56610
Check Point
Diagnosis
$ Symptoms due to connection failure of wiring/symptoms resulted from blowout of fuse
NOTE
• To access the wiring diagrams, click Wiring diagrams in Bookmarks.
Suffix number Condition
00001 Although a specified length of paper is fed in paper advance operation, paper sensor 2 does not detect DARK.
00002 While paper is fed in paper advance operation, paper sensor 2 turns LIGHT.
00003 When ejecting paper, paper sensor 2 does not turn LIGHT although a specified length of paper is fed to lead the
front end of the paper.
1 Check that a short test print has not been inserted.
2 Clean the advance rollers of the colorimeter with a cleaning sheet.
3 Carry out each correction via Colorimeter Unit Adjustment.
4 If the error of suffix number 00003 occurs without a paper in the colorimeter unit, clean the paper sensor 2.
Failed part Manual No.
Paper sensor 2 ☞63318
Paper advance motor
Processor control PCB
☞66200
Processor I/O PCB 2 ☞66211
Colorimeter unit
☞27460
Symptoms due to the wiring connection failure Symptoms of fuse blowout
− ☞4203 −
