Frontier LP7500 - Page 760

6. Electrical parts
63000
2/3
63000
Position of electrical parts (printer section)
!
!!
! Position 2
Printer section 2
11 Display module ☞66008
No. Name Symbol Manual No. Remarks
1 Printer I/O PCB 1
☞66020
2CVP PCB
☞66090 Option
3 Printer power supply 3 PS3 ☞ 66100
4 Printer power supply 1 PS1
5 Printer power supply 2 PS2
6 Printer I/O PCB 2
☞66030
No. Name Symbol Manual No. Remarks
11
10
4
5
3
2
1
6
7
9, 10
8
G085243
