6. Electrical parts
63311-5
2/7
63311-5
Positions of electrical parts (Processor section)
2 BF processing solution float switch FS2
BF refilling water level
BF processing solution level
BF safety thermostat
3 STB1 processing solution float switch FS3
STB1 refilling water level
4 STB2 processing solution float switch FS4
STB2 refilling water level
5 STB3 processing solution float switch FS5
STB3 refilling water level
6 STB4 processing solution float switch FS6
STB4 refilling water level
STB4 processing solution level
STB4 safety thermostat
7 CD effluent float switch FS7
8 BF effluent float switch FS8 Option
9 STB effluent float switch FS9
10 CD thermosensor TH1
11 BF thermosensor TH2
12 STB thermosensor TH3
13 CD replenishment solution level sensor LSE1
14 BF replenishment solution level sensor LSE2
15 STB replenishment solution level sensor LSE3
16 Refilling water tank level sensor LSE4
17 Interlock switch (Processor top cover) LS4
18 Rack stopper sensor LS14
19 Power supply cooling fan 1 FAN14 Intake
*1
20 Power supply cooling fan 2 FAN18 Exhaust
*1
21 Exhaust fan FAN20 Exhaust
*1
22 Tank cooling fan 1 FAN22 Intake
*1
23 Tank cooling fan 2 FAN23 Intake
*1
24 Tank cooling fan 3 FAN24 Intake
*1
25 Tank cooling fan 4 FAN25 Exhaust
*1
26 Tank cooling fan 5 FAN26 Exhaust
*1
27 Drive motor M3
28 CD1 circulation pump P1
29 CD2 circulation pump P2
30 BF1 circulation pump P3
31 BF2 circulation pump P4
32 STB1 circulation pump P5
33 STB2 circulation pump P6
34 STB3 circulation pump P7
35 STB4 circulation pump P8
36 CD-W refilling water pump P9
37 BF-W refilling water pump P10
38 STB1-W refilling water pump P11
39 STB2-W refilling water pump P12
40 STB3-W refilling water pump P13
41 STB4-W refilling water pump P14
No. Name Symbol Remarks
