Frontier LP7500 - Page 846

6. Electrical parts
66040
2/2
66040
Description of PCB (printer section)
TP5 Ground Possible
Fuse No. Rating Purpose Remarks
F37 T6.3 A/125 V DC+24 V−3 power supply
protection
F38 T6.3 A/125 V DC+24 V−4 power supply
protection
Test point No. Purpose Measurement with
voltmeter
Remarks
