6. Electrical parts
66860
66860
Explanation of PCBs (Processor section)
!
!!
! Component parts table
LED No. Purpose Status
LED1 to 6 Indication of prioritized order on the second rack Prioritized order being output: blinks in orange
Prioritized order ejection complete: lights in orange
LED7 to 12 Indication of prioritized order on the third rack
LED13 to 18 Indication of prioritized order on the fourth rack
LED19 to 24 Indication of prioritized order on the fifth rack
LED25 to 30 Indication of prioritized order on the sixth rack
LED31 to 36 Indication of prioritized order on the seventh rack
LED37 to 42 Indication of prioritized order on the eighth rack
LED43 to 48 Indication of prioritized order on the ninth rack
LED49 to 54 Indication of prioritized order on the second rack Output of split order: lights in blue
LED55 to 60 Indication of prioritized order on the third rack
LED61 to 66 Indication of prioritized order on the fourth rack
LED67 to 72 Indication of prioritized order on the fifth rack
LED73 to 78 Indication of prioritized order on the sixth rack
LED79 to 84 Indication of prioritized order on the seventh rack
LED85 to 90 Indication of prioritized order on the eighth rack
LED91 to 96 Indication of prioritized order on the ninth rack
