Fujitsu PRIMERGY RX2530 M4

RX2530 M4 Upgrade and Maintenance Manual 179
Hard disk drive (HDD) / solid state drive (SSD)
PCIe configuration with 2x Retimer controller in riser module 2 (slot 3) and riser
module3 (slot 4):
Label color on
the color-coded
Oculink cable
Connector on
the Retimer
controller
Connector on the
10x 2.5-inch HDD
backplane with
10x Oculink
connectors (NVME)
First Retimer
controller in slot 3
red Port 0 X1A
yellow Port 1 X2A
green Port 2 X3A
black Port 3 X4A
Second Retimer
controller in slot 4
red Port 3 X5A
yellow Port 2 X6A
green Port 1 X7A
black Port 0 X8A
Label color on
the color-coded
Oculink cable
Connector on
system board
Connector on the
10x 2.5-inch HDD
backplane with
10x Oculink
connectors (NVME)
System board
red PCIe 0 X9A
yellow PCIe 1 X10A
