Fujitsu PRIMERGY RX2530 M4

RX2530 M4 Upgrade and Maintenance Manual 195
Fans
Figure 106: CPU types, heat sink types and fan types
Skylake-SP
Socket P1
Spec RX2530 M4 Heatsink Fan Typ Heatsink Fan Typ
Max. CPU TDP
205W
Xeon Bronce 3100 - Basic (Shelf 1)
Xeon Bronce 31xx 6C/6T 1.7GHz 8.3MB 9.6GT/s 2133MHz 85W
GR
B1015-V1
A3C40201803
B1016-V2
A3C40201802
Xeon Bronce 31xx 8C/8T 1.7GHz 11.0MB 9.6GT/s 2133MHz 85W GR
B1015-V1
A3C40201803
B1016-V2
A3C40201802
Xeon Silver 4100 - Standard (Shelf 2)
Xeon Silver 41xx 8C/16T 1.8GHz 11.0MB 9.6GT/s 2400MHz 85W
GR
B1015-V1
A3C40201803
B1016-V2
A3C40201802
Xeon Silver 41xx 8C/16T 2.1GHz 11.0MB 9.6GT/s 2400MHz 85W GR
B1015-V1
A3C40201803
B1016-V2
A3C40201802
Xeon Silver 41xx 10C/20T 2.2GHz 13.8MB 9.6GT/s 2400MHz 85W GR
B1015-V1
A3C40201803
B1016-V2
A3C40201802
Xeon Silver 41xx 12C/24T 2.1GHz 16.5MB 9.6GT/s 2400MHz 85W GR
B1015-V1
A3C40201803
B1016-V2
A3C40201802
Xeon Silver 4100 - Frequency Optimized (Shelf 2)
Xeon Silver 41xx 4C/8T 2.6GHz 11.0MB 9.6GT/s 2400MHz 85W
GR
B1015-V1
A3C40201803
B1016-V2
A3C40201802
Xeon Silver 41xx 8C/16T 2.4GHz 11.0MB 9.6GT/s 2400MHz 85W GR
B1015-V1
A3C40201803
B1016-V2
A3C40201802
Xeon Gold 5100 - Advanced (Shelf 3)
Xeon Gold 51xx 12C/24T 2.4GHz 19.3MB 10.4GT/s 2400MHz 105W
GR
B1015-V1
A3C40201803
B1016-V2
A3C40201802
Xeon Gold 51xx 14C/28T 2.2GHz 19.3MB 10.4GT/s 2400MHz 105W GR
B1015-V1
A3C40201803
B1016-V2
A3C40201802
Xeon Gold 5100 - Frequency Optimized (Shelf 3)
Xeon Gold 5122 4C/8T 3.6GHz 16.5MB 10.4GT/s 2666MHz 105W
GR
B1015-V1
A3C40201803
B1016-V2
A3C40201802
Xeon Gold 6100 - Advanced (Shelf 4)
Xeon Gold 6130 16C/32T 2.1GHz 22.0MB 10.4GT/s 2666MHz 125W
GR
B1015-V1
A3C40201803
B1016-V2
A3C40201802
Xeon Gold 6140 18C/36T 2.3GHz 24.8MB 10.4GT/s 2666MHz 140W GR
B1012-V1
A3C40201802
B1016-V2
A3C40201802
Xeon Gold 6138 20C/40T 2.0GHz 27.5MB 10.4GT/s 2666MHz 125W GR
B1015-V1
A3C40201803
B1016-V2
A3C40201802
Xeon Gold 6148
20C/40T 2.4GHz 27.5MB 10.4GT/s 2666MHz 150W
GR
B1012-V1
A3C40201802
B1016-V2
A3C40201802
Xeon Gold 6152 22C/44T 2.1GHz 30.3MB 10.4GT/s 2666MHz 140W GR
B1012-V1
A3C40201802
B1016-V2
A3C40201802
Xeon Gold 6100 - Frequency Optimized (Shelf 4)
Xeon Gold 6128 6C/12T 3.4GHz 19.3MB 10.4GT/s 2666MHz 125W
GR
B1015-V1
A3C40201803
B1016-V2
A3C40201802
Xeon Gold 6134 8C/16T 3.2GHz 24.8MB 10.4GT/s 2666MHz 130W GR
B1015-V1
A3C40201803
B1016-V2
A3C40201802
Xeon Gold 6144
8C/16T 3.6GHz 24.8MB 10.4GT/s 2666MHz 165W
GR
B1016-V2
A3C40201802
B1016-V2
A3C40201802
Xeon Gold 6126 12C/24T 2.6GHz 19.3MB 10.4GT/s 2666MHz 125W GR
B1015-V1
A3C40201803
B1016-V2
A3C40201802
Xeon Gold 6136
12C/24T 3.0GHz 24.8MB 10.4GT/s 2666MHz 150W
GR
B1012-V1
A3C40201802
B1016-V2
A3C40201802
Xeon Gold 6146
12C/24T 3.4GHz 24.8MB 10.4GT/s 2666MHz 165W
GR
B1016-V2
A3C40201802
B1016-V2
A3C40201802
Xeon Gold 6132 14C/28T 2.6GHz 19.3MB 10.4GT/s 2400MHz 140W GR
B1012-V1
A3C40201802
B1016-V2
A3C40201802
Xeon Gold 6142
16C/32T 2.6GHz 22.0MB 10.4GT/s 2666MHz 150W
GR
B1012-V1
A3C40201802
B1016-V2
A3C40201802
Xeon Gold 6150
18C/36T 2.7GHz 24.8MB 10.4GT/s 2666MHz 165W
GR
B1016-V2
A3C40201802
B1016-V2
A3C40201802
Xeon Gold 6154
18C/36T 3.0GHz 24.8MB 10.4GT/s 2666MHz 200W
GR
B1016-V2
A3C40201802
B1016-V2
A3C40201802
Xeon Platinum 8100 Advanced (Shelf 4)
Xeon Platinum 815
3
16C/32T 2.0GHz 22.0MB 10.4GT/s 2666MHz 125W GR
B1015-V1
A3C40201803
B1016-V2
A3C40201802
Xeon Platinum 816
0
24C/48T 2.1GHz 33.0MB 10.4GT/s 2666MHz 150W
GR
B1012-V1
A3C40201802
B1016-V2
A3C40201802
Xeon Platinum 816
4
26C/52T 2.0GHz 35.8MB 10.4GT/s 2666MHz 150W
GR
B1012-V1
A3C40201802
B1016-V2
A3C40201802
Xeon Platinum 817
0
26C/52T 2.1GHz 35.8MB 10.4GT/s 2666MHz 165W
GR
B1016-V2
A3C40201802
B1016-V2
A3C40201802
Xeon Platinum 817
6
28C/56T 2.1GHz 38.5MB 10.4GT/s 2666MHz 165W
GR
B1016-V2
A3C40201802
B1016-V2
A3C40201802
Xeon Platinum 818
0
28C/56T 2.5GHz 38.5MB 10.4GT/s 2666MHz 205W
GR
B1016-V2
A3C40201802
B1016-V2
A3C40201802
Xeon Platinum 8100 - Frequency Optimized (Shelf 4)
Xeon Platinum 816
8
24C/48T 2.7GHz 33.0MB 10.4GT/s 2666MHz 205W
GR
B1016-V2
A3C40201802
B1016-V2
A3C40201802
Xeon Gold 6100M - Advanced (Shelf 4; 1.5TB p. Socket)
Xeon Gold 6134M 8C/16T 3.2GHz 24.8MB 10.4GT/s 2666MHz 130W
GR
B1015-V1
A3C40201803
B1016-V2
A3C40201802
Xeon Gold 6140M 18C/36T 2.3GHz 24.8MB 10.4GT/s 2666MHz 140W GR
B1012-V1
A3C40201802
B1016-V2
A3C40201802
Xeon Gold 6142M
16C/32T 2.6GHz 22.0MB 10.4GT/s 2666MHz 150W
GR
B1012-V1
A3C40201802
B1016-V2
A3C40201802
Xeon Platinum 8100M Advanced (Shelf 4; 1.5TB p. Socket)
Xeon Platinum 816
0
24C/48T 2.1GHz 33.0MB 10.4GT/s 2666MHz 150W
GR
B1012-V1
A3C40201802
B1016-V2
A3C40201802
Xeon Platinum 817
0
26C/52T 2.1GHz 35.8MB 10.4GT/s 2666MHz 165W
GR
B1016-V2
A3C40201802
B1016-V2
A3C40201802
Xeon Platinum 817
6
28C/56T 2.1GHz 38.5MB 10.4GT/s 2666MHz 165W
GR
B1016-V2
A3C40201802
B1016-V2
A3C40201802
Xeon Platinum 818
0
28C/56T 2.5GHz 38.5MB 10.4GT/s 2666MHz 205W
GR
B1016-V2
A3C40201802
B1016-V2
A3C40201802
Xeon Silver 4100 - Embedded (Shelf 2)
Xeon Silver 41xxT 10C/20T 2.0GHz 13.8MB 9.6GT/s 2400MHz 70W
GR
B1015-V1
A3C40201803
B1016-V2
A3C40201802
Xeon Gold 5100 - Embedded (Shelf 3)
Xeon Gold 51xxT 14C/28T 2.0GHz 19.3MB 10.4GT/s 2400MHz 70W
GR
B1015-V1
A
3C40201803
B1016-V2
A
3C40201802
ATD35 ATD40 or ATD45
