336 Upgrade and Maintenance Manual RX2530 M4
13.1.2 Installing the ODD
13.1.2.1 Preliminary steps
Ê "Suspending BitLocker functionality" on page 77
Ê "Shutting down the server" on page 49
Ê "Disconnecting the power cord" on page 50
Ê "Getting access to the component" on page 52
13.1.2.2 Removing the dummy cover
Figure 244: Removing the dummy cover
Ê Pull the dummy cover out of the bay.
V CAUTION!
Keep the dummy cover for future use. If you remove the accessible drive
again and do not replace it with a new one, the dummy cover must be
reinstalled to comply with EMC regulations and to satisfy cooling
requirements and fire protection measures.
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Tools: – Torx Plus 6 screw driver (not valid for Japan)
– Phillips PH1 / (+) No. 1 screw driver (Japan)
