Fujitsu PRIMERGY RX2530 M4

416 Upgrade and Maintenance Manual RX2530 M4
Appendix A
Pos. Print Description
1 Internal USB3.0 Connector for Dual microSD 64GB Enterprise
2 Front VGA Connector for optional front VGA
3 USB 3.0 FRONT Front USB connector
4 HDD PWR3 Power connector for HDD backplane
5 LC2 Connector for LC pump for CPU 2
6 FRONTPANEL1 Front panel connector
7 FAN 15/16 Power connector for system fan 15 and 16
8 FAN 13/14 Power connector for system fan 13 and 14
9 FAN 11/12 Power connector for system fan 11 and 12
10 FAN 9/10 Power connector for system fan 9 and 10
11 FAN 7/8 Power connector for system fan 7 and 8
12 FAN 5/6 Power connector for system fan 5 and 6
13 LC1 Connector for LC pump for CPU 1
14 FAN 3/4 Power connector for system fan 3 and 4
15 FAN 1/2 Power connector for system fan 1 and 2
16 PWR2
Power connector for ODD
17 SMB4 (I2C5) OOB (Out-Of-Band) connector for HDD backplane
18 SATA 4-7
SATA HDD connector
19 SATA 0-3 SATA HDD connector
20 HDD LED Connector for HDD LED cable (e.g. PRAID EP5xxi)
21 SATA ODD SATA connector for ODD
22 TPM Connector for optional TPM
23 M.2 SSD2 M.2 slot 2
24 M.2 SSD1 M.2 slot 1
25 SERIAL (COM1) Connector for optional serial interface
26 micro SD iRMC microSD card
27 PSU2 Power connector for PSU 2
28 ROC Connector for Dual microSD 64GB Enterprise cable
29 PSU1 Power connector for PSU 1
