190-01263-01 Rev. A
Garmin G2000 Pilot’s Guide for the Cessna T240
93
Flight instruments
sYstem
OVerVieW
Flight
instruments
eis
AuDiO PAnel
& Cns
Flight
mAnAgement
hAZArD
AVOiDAnCe
AFCs
ADDitiOnAl
FeAtures
APPenDiCes inDeX
AIRPORT SIGNS
Airport Signs provide a visual representation of airport location and identification on the synthetic terrain
display. When activated, the signs appear on the display when the aircraft is approximately 15 nm from an
airport and disappear at approximately 4.5 nm. Airport signs are shown without the identifier until the aircraft
is approximately eight nautical miles from the airport. Airport signs are not shown behind the airspeed or
altitude display. Airport signs are activated and deactivated by pressing the Airport Signs Softkey.
Figure 2-37 Airport Signs
Airport
Sign with
Identifier
(Between
4.5 nm and
8 nm)
Airport
Sign
without
Identifier
(Between
8 nm and
15 nm)
