5-22 Section 5-4 - Main Board Detail
5-4-4-2 BIOS Content (cont’d)
Figure 5-20 Advanced menu in BIOS
Advanced Advanced
ACPI Settings Advanced PCI/PnP Settings
ACPI Aware O/S [Yes] Plug & Play OS [No]
ACPI 2.0 Feature [No] PCI Latency Timer [64]
ACPI APIC Support [Enabled] Allocate IRQ to PCI VGA [Yes]
Suspend Mode [S1 (POS)] Allocate IRQ to SMBUS HC [Yes]
USB Device Wakeup from S3/S4 [Disabled]
Active Cooling Trip Point [Disabled] PCI IRQ Resource Exclusion
Passive Cooling Trip Point [90
℃
]
Critical Trip Point [110] PCI Interrupt Routing
Watchdog ACPI Event [Shutdown]
GPE1 Function [No Function]
GPE2 Function [No Function]
Advanced Advanced
Graphics Configuration Configure advanced CPU settings
Module Version : xxx
Primary Video Device [Internal VGA]
Internal VGA Mode Select [Enabled, 8MB] Manufacturer : Intel
Aperture Size Select [256MB] Brand String : Intel® Pentium® M Processor 1.8
DVMT Mode Select [DVMT Mode] Frequency : 1.80GHz
DVMT/FIXED Memory [128MB] FSB Speed : 400MHz
Boot Display Device [CRT + LFP]
Boot Display Preference [LEP SDVO-B SDVO-C] Cache L1 : 32KB
Local Flat Type [Customized EDID] Cache L2 : 2048KB
Local Flat Type Scaling [Expand Text & Grap]
SDVO Port B Device [None] Intel® Speedstep
™
tech [Automatic]
SDVO Port C Device [None] Max. CPU Frequency [1800Mhz]
Backlight Control [100%]
TV Standard [VBIOS-Default]
Advanced Advanced
Advanced Chipset Settings I/O Interface Configuration
Memory Hole [Disabled]
Onboard Audio Controller [AC97]
IOAPC [Enabled] Onboard Ethernet Controller [Enabled]
APIC ACPI SCI IRQ [Disabled] Onboard Floppy Controller [Disabled]
C4 on C3 [Disabled] Floppy A [Disabled]
DMI Power Management [Disabled] Serial Port 1 Configuration [Disabled]
Serial Port 2 Configuration [Disabled]
PCI Express Configuration Parallel Port Address [Disabled]
PCI Express Port 1 [Disabled]
PCI Express Port 2 [Disabled]
PCI Express Port 3 [Disabled]
PCI Express Port 4 [Disabled]
VC1 for Azlia & Root Ports [Disabled]
BIOS SET UP UTILITY BIOS SET UP UTILITY
BIOS SET UP UTILITY BIOS SET UP UTILITY
BIOS SET UP UTILITY BIOS SET UP UTILITY
