Installation of the HP LaserJet CP2025/M451 Color Printer requires configuring the IP addresses for
both the Vivid S5 N/ Vivid S6 N system and for the printer. There are two types of installations, as
described below:
- “Peer-to-Peer” using a cross communication cable between the system and the printer.
See Peer-to-Peer Configuration, below.
- Printer installation on a network (e.g. a hospital network).
See ‘Installing the HP LaserJet CP2025 Color Printer on a Network” on page 3-59.
3-5-1-5-1 Peer-to-Peer Configuration
Defining the IP address of the Vivid S5 N/ Vivid S6 N System
1.) Using a service dongle, boot up the system in Maintenance mode and exit to the Windows Desktop.
2.) Click Start > Control Panel and navigate to Network Connections.
3.) In the Network Connections screen, select Local Area Connection 2.
4.) On the console, press Update/Menu to access the context menu and then click Properties.
