ART NUMBER FN091065, REVISION 2 VS5 N AND VS6 N SERVICE MANUAL
Chapter 8 - Replacement Procedures 8-121
PRELIMINARY
8-6-3-5 Battery Bracket Installation Procedure
NOTE: When performing the following installation procedure steps, it may be helpful to review the appropriate
movie clips previously referenced in the 8-6-3-4 "Battery Bracket Removal Procedure" on page 8-119.
1.) Working with the battery bracket upside down on the table surface (and close to the system),
reconnect the battery cable (attached to the battery bracket) to the BEP (see Figure 8-149 on
page 8-120).
2.) Carefully lift the battery bracket back and turning it over, swing into position on the cage assembly
(see Figure 8-148 on page 8-120).
3.) Slide the bracket in place and make sure it is seated correctly.
4.) Return and fasten the four screws (previously removed) to secure the battery bracket to the cage
assembly, as indicated in Figure 8-147 on page 8-119.
5.) Return the battery, as described in the 8-6-2-5 "Battery Installation Procedure" on page 8-118.
6.) Carefully secure the cables with new cable tie wraps.
7) Return the cabinet cage assembly to the system, reconnect the cables (previously disconnected),
close the cabinet cage door and fasten securely with the two latches.
Refer to the 8-6-1-4 "Cabinet Cage Assembly Closing and Installation Procedure" on page 8-114.
8) Return the front cover, as described in the 8-2-6-4 "Front Cover Installation Procedure" on page 8-
19.
9) Return the left and right side covers, as described in the 8-2-3-4 "Left Side Cover Installation
Procedure" on page 8-7 and See “Right Side Cover Installation Procedure” on page 5..
10.)Turn ON power to the system.
11.)Proceed to perform the following functionality tests:
- 10-6-4 "Grounding Continuity" on page 10-23
- 10-6-5 "Chassis Current Leakage Test" on page 10-24
