GE Vivid S5 N - 8-6-9-5 PIB Board Installation Procedure

GE
P
ART NUMBER FN091065, REVISION 2 VS5 N AND VS6 N SERVICE MANUAL
Chapter 8 - Replacement Procedures 8-155
PRELIMINARY
8-6-9 PIB (Probe Interface Board) Board Replacement Procedure (cont’d)
8-6-9-5 PIB Board Installation Procedure
NOTE: When performing the following installation procedure steps, it may be helpful to review the movie clips
previously referenced in the 8-6-9-4 "PIB Board Removal Procedure" on page 8-153.
1) Return a new PIB Board to the appropriate location on the cabinet cage assembly - refer to Figure
8-189.
2.) Return and fasten the five screws (previously removed) to secure the PIB Board in position.
3.) Reconnect the PIB-to-PSB flex cable to the PIB Board, then return and fasten the screw (previously
removed) to secure the flex cable in position (Figure 8-188).
4) Fold the cabinet cage assembly in the closed position and secure by fastening each of the two
thumbscrews.
5) Return the cabinet cage assembly to the system, reconnect the cables (previously disconnected),
close the cabinet cage door and fasten securely with the two latches.
Refer to the 8-6-1-4 "Cabinet Cage Assembly Closing and Installation Procedure" on page 8-114.
6) Return the Vivid S6 N front cover, as described in the 8-2-6-4 "Front Cover Installation Procedure"
on page 8-19.
7) Return the Vivid S6 N left and right side covers, as described in the 8-2-3-4 "Left Side Cover
Installation Procedure" on page 8-7 and 8-2-2-4 "Right Side Cover Installation Procedure" on page
8-5.
8.) Turn ON power to the system.
9.) Proceed to perform the following functionality tests:
- 10-6-4 "Grounding Continuity" on page 10-23
- 10-6-5 - Chassis Current Leakage Test
- 7-2-4-2-1 "Calibration" on page 7-12
- 7-2-4-1 "Full System Test" on page 7-11
- 4-3-1-8 "Front End Tests" on page 4-25
- 4-3-1-9 "Visual Test" on page 4-32
