Figure6.5.1.6
Figure6.5.1.7
(6) dt, 1/dt and dSamp
When the segment is selected by reference lines, three values (dt, 1/dt and dSamp) will be shown
below the graph as figure 6.5.1.3.
dt: The time of the selected segment
dSamp: The number of the samples in the selected segment
Values will not be
automatically updated to
fit the graph.
