D1 Servo Drive User Manual LCD Display
HIWIN MIKROSYSTEM CORP. 7-17
Gear ratio of AC servo motor
Offset correction of analog input
The numerator of electronic gear
ratio (output)
The denominator of electronic
gear ratio (input)
The scaling of velocity command
The corresponding velocity of unit
voltage (Suggested value: Rated
velocity/10)
Deadband of velocity command
When input voltage is smaller than
this setting value, velocity
command is 0.
The scaling of current command
The corresponding current of unit
voltage
Deadband of current command
When input voltage is smaller than
this setting value, current
command is 0.
Warning threshold of position
error
Warning threshold of velocity error
Resistance of motor (Line-Line)
Refer to the
catalogue of
motor.
Inductance of motor (Line-Line)
Refer to the
catalogue of
motor.
Velocity for activating brake
Delay time for activating brake
Multiplier factor of analog encoder
Pulse type
0: Quadrature(AqB)
1: Pulse/Direction
2: Pulse up/Pulse down
(CW/CCW)
Invert pulse command.
0: Do not invert.
1: Invert.
Trigger method of pulse command
0: Falling edge
1: Rising edge
Command input type in velocity
mode and force/torque mode
0: Analog
1: PWM 50%
