HP 8560A

Instrument Variations
The following text lists the unique assemblies contained in the HP 8560A Options 001, 002,
003, and all combinations.
HP 8560A Option 001 (Rear-Panel 2nd IF Output)
Al5 RF Assembly
unique part number
w19
added
Rear-panel JlO
added
HP 8560A Option 002 (Tracking Generator)
A10 Tracking Generator
Al5 RF Assembly
Front dress-panel
w14
W16
W36
W42
w43
W46
w47
W48
Rear-panel J 11
Front-panel 53
Front-panel J6
added
unique part number
unique part number
added
added
deleted
deleted
added
added
added
added
added
deleted
added
HP 8560A Option 012 (001 + 002)
Al5 RF Assembly unique part number
w19 added
Rear-panel JlO
added
A10 Tracking Generator
added
Front dress-panel
unique part number
w14 added
W16
added
W36
deleted
W42 deleted
w43
added
General Information 1-3
