HP 8560A

585 RBW 300K
586 RBW IM
587 RBW 30K
588 RBW IOOK
589 RBW 300K
590 RBW IM
591 LOG AMPL
592 LOG AMPL
593 LOG TUNE
594 LOG OFST
595 LOG ATTN
596 LOG FID
597 LOG OFST
598 LOG OFST
599 LOG GAIN
Unable to adjust 300 kHz Resolution Bandwidth. SYSBW and LCBW
disagreement in LCCAL.
Unable to adjust 1 MHz Resolution Bandwidth. SYSBW and LCBW
disagreement in LCCAL.
Unable to adjust 30 kHz Resolution Bandwidth. SYSBW and LCBW
disagreement in LCCAL.
Unable to adjust 100 kHz Resolution Bandwidth. SYSBW and LCBW
disagreement in LCCAL.
Unable to adjust 300 kHz Resolution Bandwidth. SYSBW and LCBW
disagreement in LCCAL.
Unable to adjust 1 MHz Resolution Bandwidth. SYSBW and LCBW
disagreement in LCCAL.
Unable to adjust amplitude of log scale. No power sweep in find
compression point.
Unable to adjust amplitude of log scale. No compression BOW in find
compression point.
LIMIT Cal tune error from DC Logger Calibration.
Attenuator Calibration Offset error from DC Logger Calibration.
Attenuator Calibration Absolute error from DC Logger Calibration.
Fidelity error from DC Logger Calibration.
Fidelity Offset error from DC Logger Calibration.
Fidelity Offset unstable from DC Logger calibration.
Fidelity Gain error from DC Logger calibration.
System Errors (600 to 651)
ADC timeout errors occur if the A2 Controller assembly frequency
counter is faulty. Refer to Chapter 7, “ADC/Interface Section.”
600 SYSTEM
Hardware/firmware interaction; check other errors.
601 SYSTEM
Hardware/firmware interaction; check other errors.
650 OUTOF RG
ADC input is outside of the ADC range.
651 NO IRQ
Microprocessor is not receiving interrupt from ADC.
Digital and Checksum Errors (700 to 799)
EEROM Checksum Errors (700 to 704)
Faults on the A2 Controller assembly can cause these errors. Refer
to Chapter 9, “Controller Section.” Although some of these errors
might result in a blanked display, it is possible to read these errors
over HP-IB. Refer to “Troubleshooting to a Functional Section” in this
chapter.
General Troubleshooting 6-3 1
