HP 8560A Service Manual

Frequency Counter
See function block 2 of A2 Controller Schematic Diagram (sheet 4 of 4) in the
Component-Level Information binder.
The frequency counter counts the frequency of the last IF and provides accurate timing signals
for digital zero-spans. The circuit also provides timing signals to the A3 Interface assembly’s
ADC (Analog to Digital Converter). The nominal input frequency is 5.35 MHz (10.7 MHz
divided by 2). The circuit’s frequency reference is the 10 MHz reference from the Al5 RF
assembly.
In the frequency count mode,
U702 prescales the 10 MHz reference by 5 to generate, a 2 MHz
timebase. This timebase feeds through MUX U704 to programmable-timer U7OO’s CLK2
input. Programmable-timer U7OO’s output (OUT2) is the gating signal (HBKT-PULSE)
for performing the frequency count. The gating time interval is a function of the counter
resolution which may be set between 10 Hz and 1 MHz. Table 9-2 lists the Gate Time for
each setting of COUNTER RES. The gate time is the period during which U511 pin 3 is high.
The FREQ COUNT input,
A2J7, is gated in U511B by HBKT-PULSE. The gated signal
clocks divide-by-16 counters U703A and U703B. These counters are cascaded to form a
divide-by-256 counter. The MSB of this counter, CD7, clocks the CLKO input of U700. The
frequency of CD7 is a function of COUNTER RES as shown in Table 9-2. If Timer U700
overflows, OUT0 will be set and U701B clocked, generating CNTOVFLIRQ, which will
interrupt the CPU.
If IRQAK2 is high, HBKT_PULSE will clock U701A, generating FREQCNTLIRQ. Upon
receiving the FREQCNTLIRQ interrupt, the CPU latches the CD0 to CD7 onto the BID
bus by setting LCDRD
(1 ow counter data read) low and reading the counter data from the
BID bus. The CPU will also read the data from the timer,
U700, by setting L8254CS and
LCNTLRD low, placing-the timer data on the BID bus. The CPU resets U701A by setting
IRQAK2 low via the BID bus and latch U506.
Table 9-2. Gate Times
Counter Res
Gate Time*
(U511 pin 3 high state)
200 ms
20 ms
10 Hz
2 MHz
4.18 kHz
100 Hz
2 MHz
418Hz
1 kHz
2
ms
2 MHz
41.8
Hz
10 kHz
2
ms
2 MHz
41.8
Hz
100 kHz
2 ms
2 MHz
41.8Hz
1 MHz
1 2
ms 1 2 MHz
1 41.8 Hz
* TP15 = (FREQ COUNT input x Gate Time)/256
A2TP16
A2TP15
9-14 Controller Section
