HP 8560A

Table 10-5. TAM Tests versus Test Connectors (1 of 2)
Connector Manual Probe Troubleshooting Test Measured Signal Line,
A14J 15 Sweep Generator
MS8
Span Attenuator DAC
MS7
Span Attenuator Switches
MS7
Sweep + Tune Mult Input Amp
MSl, OS1
Sweep + Tune Mult Input Switches
MSl, MS3
VCO Sweep Driver
MS6, OS1
A14J 16 FAV Generator
MS4
FAV Gen 0.5 V/GHz Output
MS5
YTF Offset DAC
MS6
YTF Gain and Offset Input
MS2
YTF Gain DAC
MS1
YTF Drive
MS3
Band Switch Driver
MS8
Al4J17 Main Coil Course DAC
MS3
Main Coil Fine DAC
MS2
Main Coil
DACs Output
MS5
YTO Loop Phase Detector
MS1
Main Loop Error Volt DVR MS4
Option Drive
MS8
Option Drive Switch
MS7
Option Drive DAC
MS6
A14J18 f10 V Reference
MSl, MS2
LODA Drive MS5, MS6, MS7, MSE
A14J19 Main Coil Tune DAC
MS3
Sweep Generator DAC
MS4
Sweep Generator Switches MS4
Second Conv PIN Switch
MS8
Second Conv Mixer Bias
MS1
Second Conv Drain Bias MS3
Second Conv Doubler Bias
MS4
Second Conv Driver Bias MS5
First Mixer Drive Switch
MS7
First Mixer Drive DAC MS6
A145302 Revision MS7
XFER Osc Bias MS1
XFER Pretune DAC MS6
Offset Osc Bias
MS2
Offset Pretune DAC MS8
Offset Amp Bias MS5
Synthesizer Section
lo- 11
