HP 8560A

REF
10.0 dBm ATTEN 20 dB
10 dB,’
SAMPLE
CENTER 10.700 000 MHz SPAN 0 Hz
RES BW 300 kHz VBW 1 kHz SWP 1.40 set
SK176
REF
10 dB/
SAMPLE
r
Figure 8-7. Detailed IF Adjust Signature (4)
0 dBm
.I
ATTEN 20 dB
CENTER 10.700 000 MHz SPAN 0 Hz
RES BW 300 kHr VBW 1 kHz SWP 2.00 set
SK177
Figure 8-8. Detailed IF Adjust Signature (5)
IF Section 8-27
