HP 8560A

REF
10.0
dBm ATTEN 20 dB
5 dB/
SAMPLE
I I I I I I I I
CENTER 10.700 000 MHz
SPAN 0 Hz
RES BW 300
kHz
VBW 300 kHz
SWP 500 msec
SK174
Figure 8-5. Detailed IF Adjust Signature (2)
REF 10.0 dBm
ATTEN 20 dB
10 dB/
SAMPLE
/
I
1
CENTER 10.700 000 MHz
SPAN 0 H
RES BW 300
kHz
VBW 300 kHz
SWP 1.4 set
SK175
Figure 8-8. Detailed IF Adjust Signature (3)
8-26 IF Section
