Table 2-4. TAM Adjustments
TAM Adjustment
Corresponding Manual Adjustment
Adjustment
Number
1. IF Bandpass, LC Poles
IF Bandpass Adjustment
3
2. IF Bandpass, Crystal Poles
IF Bandpass Adjustment
3
3. IF Amplitude
IF Amplitude Adjustment
4
4. Limiter Phase
DC Log Amplifier Adjustments, A4 Limiter Phase
5
5. Linear Fidelity
DC Log Amplifier Adjustments, A4 Linear Fidelity
5
6. Log Fidelity
DC Log Amplifier Adjustments, A4 Log Fidelity
5
7. Sampling Oscillator
Sampling Oscillator Adjustment
6
8. YTO YTO Adjustment
7
9. LO Distribution Amp
First LO Distribution Amplifier Adjustment
8
10. Low Band Flatness
Frequency Response Adjustment
10
11. Calibrator Amplitude Calibrator Amplitude Adjustment
11
12. 10 MHz Reference Oscillator 10 MHz Reference Adjustment - TCXO
19
(Option 003)
13. External Mixer Bias *
External Mixer Bias Adjustment
14. External Mixer Amplitude * External Mixer Amplitude Adjustment
* Adjustment excluded if the HP 8560A is an Option 002.
14
15
Table 2-5. Required Test Equipment for TAM
Adjustment
1. IF Bandoass. LC Poles
Equipment Used Required Recommended
Model Model
None
2. IF Bandpass, Crystal Poles None
3. IF Amplitude Synthesizer/Level Generator HP 3335A
Test Cable (SMB to BNC) 85680-60093
Manual Probe Cable
4. Limiter Phase
Synthesizer/Level Generator HP 3335A
Test Cable BNC
HP 10503A
5. Linear Fidelity
Synthesizer/Level Generator HP 3335A
Test Cable BNC
HP 10503A
