16. Second IF Gain Adjustment
Table 2-13. A15U802 Values
Second IF Amplifier
U802
Value
Gain Range
(dB)
(dB)
13.1
to
14.2
1
14.3
to
15.2
2
15.3
to
16.2
3
16.3
to
17.2
4
17.3
to
18.2
5
18.3
to
19.2
6
19.3
to
20.2
7
Second
IFA
Pad
Part Number
0955-0308
0955-0309
0955-0310
0955-0311
0955-0312
0955-0313
0955-0314
