Table 6-1. Location of Assembly Troubleshooting Texi
Instrument
Assembly
AlAl Keyboard
AlA RPG
A2 Controller
A3 Interface
A4 Log Amplifier/Cal
Oscillator
A5 IF
A6 Power Supply
A6Al HV Module
A7 1ST LO Dist. Ampl.
A8 Low Band Mixer
A9 Input Attenuator
A10 Tracking Generator
All YTO
413 2nd Converter
414 Frequency Control
Al5 RF Assembly
Al7 CRT Driver
A18 CRT
A19 HP-IB
FL1,2
Location of Troubleshooting Text
Chapter 7. ADC/Interface Section
Chapter 7. ADC/Interface Section
Chapter 9. Controller Section
Chapter 7. ADC/Interface Section
Chapter 8. IF Section
Chapter 8. IF Section
Chapter 8. IF Section
Chapter 12. Display/Power Supply Section
Chapter 12. Display/Power Supply Section
Chapter 10. Synthesizer Section
Chapter 11. RF Section
Chapter 11. RF Section
Chapter 11. RF Section
Chapter 10. Synthesizer Section
Chapter 11. RF Section
Chapter 10. Synthesizer Section
Chapter 11. RF Section
Chapter 10. Synthesizer Section
Chapter 11. RF Section
Chapter 12. Display/Power Supply Section
Chapter 12. Display/Power Supply Section
Chapter 9. Controller Section
Chapter 11. RF Section
General Troubleshooting 6-9
