HP 8560A

Component-Level Information Packets
Component-Level information is available for selected instrument assemblies. The information
for each repairable assembly is provided in the form of Component-Level Information Packets
(CLIPS). Each CLIP
contains a parts list, component-location diagram, and schematic
diagram. Each CLIP has an HP part number which is changed whenever the HP part number
for its related instrument assembly is changed.
Table A-l lists board assembly part numbers and corresponding component-level information
packet (CLIP) part numbers. Table A-2 lists documented A4 Log Amplifier and Al6 CAL
OSC Board Assemblies shipped with HP 8560A Spectrum Analyzers serial prefixed below
3207A. Table A-3 lists documented RF board assemblies shipped with HP 8560A Spectrum
Analyzers serial prefixed below 3029A.
Updated or replacement CLIPS may be ordered through your local Hewlett-Packard Sales or
Service office using the CLIP part numbers provided in the following tables.
A complete set of the latest version of CLIPS can be ordered using HP Part Number
5958-7187.
CLIPS are packaged in protective plastic envelopes. To use and store your CLIPS effectively,
the following accessories are available.
2-l/2 inch CLIP binder (for 25 to 30 packets) HP part number 9282-1134
2 inch CLIP binder (for 15 to 25 packets)
HP part number 9282-1133
l-1/2 inch CLIP binder (for fewer than 15 packets)
HP part number 9282-1132
Replacement plastic CLIP envelopes
HP part number 9222-1536
Note
CLIPS may not be available for recently introduced assemblies.
Component-Level Information Packets A-l
