HP 8560A

7. YTO Adjustment
YTO FM Coil Adjustments
13. On the HP 856OA, press (PRESET) and set the controls as follows:
CENTER FREQ
. . . :. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .300 MHz
SPAN
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ...20 MHz
14. Adjust A14R76 FM SPAN until the 300 MHz CAL OUTPUT SIGNAL is aligned with the
center vertical graticule line.
Adjustment Procedures 2-39
