9. Tracking Generator Power Level Adjustments
10. Set the TRK GEN RF POWER to -10
dBm.
Note the power displayed on the measuring
receiver.
Power at -10
dBm
Setting
dBm
11. Proceed with steps 12 through 14 only if the power level noted in the previous step was
outside the range of -10
dBm
+/-.23 dB.
12. With the TRK GEN RF POWER set to -10
dBm,
adjust
AlOR
-10 dB ADJ for a
-10
dBm
+/-.l dB reading on the measuring receiver.
Refer to Figure 2-12 for adjustment
location.
13. Set the TRK GEN RF POWER to 0
dBm.
Adjust
AlOR
0 dB ADJ for a 0
dBm
f0.2
dB reading on the measuring receiver. Refer to Figure 2-12 for adjustment location.
14. Repeat steps 12 and 13 until the output power level is within the tolerances indicated at
both the -10
dBm
and 0
dBm
TRK GEN RF POWER settings. Adjust -10 dB ADJ
only with the TRK GEN RF POWER set to -10
dBm
and adjust 0 dB ADJ only with
the TRK GEN RF POWER set to 0
dBm.
2-44 Adjustment Procedures
