Part Options 254

Motion Path

This drawing shows a typical edge detection sequence for the Automatic Align feature with Corner

selected as lower left and Skew point selected as upper left on the Align screen. Alternate start

points and sequence and may be used by selecting different Corner to Align and Skew Point

parameters.

Start

Distance D
