Icom ID-51A User Manual

2
USING A microSD CARD
2-4
■ Inserting the microSD card (Continued)
D Formatting the microSD card
q Turn ON the transceiver.
w Push [MENU] .
e Push D-pad() to select the root item (“SD Card”),
and then push D-pad(Ent).
D-pad
()
(Ent)
r Push D-pad() to select “Format,” and then push D-
pad(Ent).
• The dialog “Format OK?” appears.
t Push D-pad() to select “YES,” and then push D-
pad(Ent) to format.
• The formatting starts and the display shows the format-
ting progress.
• NEVER turn OFF the power while formatting.
y After formatting, the display automatically returns to
the SD CARD menu.
u Push [MENU] to exit the MENU screen.
Appears
when the
microSD card
is inserted.
Shows the
formatting
progress
Previous view

Icom ID-51A Specifications

General

Frequency Range	144-148 MHz, 430-450 MHz
Antenna Connector	SMA
GPS Receiver	Yes
Waterproof	IPX7
Modes	FM, DV
Weight	255 g
Memory Channels	1304 channels
Output Power	5W (High), 2.5W (Middle), 0.5W (Low)
