18
OPTIONS
18-5
■ VOX function
The transceiver has a VOX function, which allows
hands-free operation.
An optional HS-94, HS-95 or HS-97 headset and the
OPC-2006LS plug adapter cable are required.
• The VOX (voice operated transmission) function starts trans-
mission when you speak into the microphone, without need-
ing to push [PTT]. It then automatically returns to reception
when you stop speaking.
NOTE: Set the external microphone gain before set-
ting the VOX gain in the MENU screen. We recom-
mend you set the microphone gain level to 3.
(MENU > Function > MIC Gain (External))
D Optional unit connection
q Turn OFF the transceiver.
w Lift up the jack cover.
e Connect the HS-94, HS-95 or HS-97 and the OPC-
2006LS, as illustrated to the right.
D Selecting the headset type
Before using the VOX function, select the headset
type.
q Turn ON the transceiver.
w Push [MENU] .
e Push D-pad() to select the root item (“Function”),
and then push D-pad(Ent) to go to the next screen.
(MENU > Function > VOX > Headset Select)
r Refer to the menu sequence shown directly above
and push D-pad() to select, and then D-pad(Ent)
to enter, one or more times until the last screen is
displayed.
t Push D-pad() to select the option.
HS-95: Select when using the HS-95.
Other: Select when using the HS-94 or HS-97.
y Push [MENU] to exit the MENU screen.
OPC-2006LS
HS-94
Transceiver
TIP: Be sure to turn OFF power when plugging in or
unplugging the OPC-2006LS into or from the [MIC/
SP] jack.
