2
USING A microSD CARD
2-6
Memory channels, item settings in the menu screen,
and Repeater List can be saved on the microSD card.
Saving data on the microSD card allows you to eas-
ily restore the transceiver to its previous configuration,
even if an All reset is performed.
TIP: Data is saved in the “icf” file format that is used in
the CS-51PLUS2 cloning software. The saved data on
the microSD card can be copied onto a PC and edited
with the cloning software. Data can be saved as a new
file or to overwrite an older file.
Saved as a new file
q Push [MENU]
.
w Push D-pad() to select the root item (“SD Card”),
and then push D-pad(Ent).
e Push D-pad() to select “Save Setting,” and then
push D-pad(Ent).
r Push D-pad() to select “<<New File>>,” and then
push D-pad(Ent).
• The FILE NAME screen is displayed.
• The file name is automatically named in the following for-
mat; Setyyyymmdd_xx (yyyy: Year, mm: month, dd: day,
xx: serial number)
Example: If a 2nd file is saved on October 1, 2016, the
file is named “Set20161001_02”.
• If you want to change the file name, see page 2-8 for
entry details.
t Push D-pad(Ent) to save the file name.
• The confirmation screen “Save file?” appears.
y Push D-pad() to select “YES,” then push D-pad(Ent)
to save.
• While saving, a progress bar is displayed, then the “SD
CARD” screen is displayed after the save is completed.
u Push [MENU] to exit the MENU screen.
■ Saving data onto a microSD card
