17
OTHER FUNCTIONS
17-8
■ Using the DTMF memory
The transceiver can stores up to 16 channels of DTMF
memory with 24-digit DTMF code.
D DTMF code programming
q Push [MENU] to select the MENU list screen.
w Push D-pad() to select the root item (“DTMF/T-
CALL”), and then push D-pad(Ent).
e Push D-pad() to select “DTMF Memory,” and then
push D-pad(Ent).
• DTMF memory channel list (d0 to d#) is displayed.
r Push D-pad() to select the desired DTMF memory
channel, then push [QUICK] .
t Push D-pad() to select “Edit,” and then push D-
pad(Ent) to enter DTMF memory edit mode.
y Rotate [DIAL] to select the desired code, the push
D-pad(Ent) to set the code.
Repeat the above step to enter the desired DTMF
codes.
• Push D-pad() to move the cursor forward or backward.
When the cursor is on the 24th digit, the cursor can be
moved to backward.
• Push [CLR]
to delete the selected character, or hold
down [CLR]
to continuously delete the characters,
first to the right, and then to the left of the cursor.
u When all digits are set, push D-pad(Ent).
• The entered DTMF codes are stored into the DTMF
memory channel, and the transceiver automatically re-
turns to DTMF memory screen.
i
Push [MENU] to exit the DTMF memory edit
mode.
Example: Stores the DTMF code, “012345” into the
DTMF memory channel “d0.”
Stored DTMF code
TIP: You can clear the programmed DTMF code.
➥ Push D-pad() to select “Clear” in the step r as
described above, and then push D-pad(Ent)
DTMF memory edit mode
Cursor
To Next Page
